PH1.25mm Wafer Horizontal SMT Type Pin header

The YZTECH PH1.25mm Horizontal SMT Wafer Housing Terminal delivers precision-engineered connectivity tailored for space-constrained designs where vertical clearance is critical. This single-row, 4-position male header connector features a horizontal orientation that aligns the mating interface parallel to the PCB, minimizing assembly height while maintaining robust electrical performance. Constructed with phosphor bronze contacts plated uniformly with tin, it supports 1A current and 125V voltage ratings, ensuring reliable signal integrity. The high-performance LCP housing provides exceptional thermal stability and mechanical resilience, operating reliably from -25°C to +85°C and withstanding high-temperature reflow soldering without warping or deformation.



Designed for seamless integration into SMT production lines,this wafer Pin Header incorporates precision-engineered coplanarity control to ensure consistent solder joint reliability during high-speed pick-and-place operations.The LCP material’s resistance to thermal stress minimizes warpage,enhancing assembly yield and process efficiency.Supplied in industry-standard reel packaging, it supports automated equipment compatibility, reducing manual handling and enabling cost-effective high-volume fabrication while maintaining stringent quality standards.



Perfectly suited for space-optimized designs,this Connector excels in ultra-slim devices such as Bluetooth modules, smart wearables,ultra-thin client systems, and portable audio equipment.Its low-profile architecture maximizes internal space utilization, enabling innovative form factors where traditional vertical connectors are impractical. Engineered for durability and performance, it empowers next-generation electronic designs requiring minimal footprint without compromising electrical or mechanical integrity.
